| Material: | AA6061-T6 |
| Specification: | ISO 11118 compliant, TPED Pi certified |
| DOT-3AL compliant & certified | |
| Volume: | 10L- 54L (200bar) |
| 9.5L- 43.4L (1800psi) | |
| Diameter: | 203.2, 218, 229, 250mm |
| Thread: | 25E / 1.125-12 UNF |
| Finish: | brushed polish (standard finish) |
| powder coating / clear coating (optional) | |
| Graphic: | label / silkscreen logo (optional) |
| Accessories: | valve / protection cap installed upon request |
ISO 7866 Series
Water Volume (l) | Work Pressure (bar) | Test Pressure (bar) | O₂ Capacity (l) | N₂ Capacity (l) | Diameter (mm) | Length (mm) | Weight (kg) |
| 30 | 200 | 300 | 6415 | 5798 | 229 | 1110 | 34.57 |
| 40 | 200 | 300 | 8554 | 7731 | 229 | 1435 | 43.76 |
| 50 | 200 | 300 | 10692 | 9664 | 250 | 1500 | 54.64 |
| Custom dimensions / specifications available upon request | |||||||
DOT-3AL Series
Water Volume (l) | Work Pressure (psi) | Test Pressure (psi) | CO₂ Capacity (lbs) | Diameter (mm) | Length (mm) | Weight (kg) |
| 23.4 | 1800 | 3000 | 35 | 203.2 | 965 | 16.67 |
| 33.4 | 1800 | 3000 | 50 | 218 | 1180 | 21.84 |
| Custom dimensions / specifications available upon request | ||||||
