| Material: | AA6061-T6 |
| Specification: | ISO 7866 compliant |
| TPED Pi (2010/35/EU) certified | |
| Volume: | 0.29L-54L |
| Diameter: | 60, 70, 89, 101, 111, 120, 140, 152, |
| 175, 184, 203, 229, 250 mm | |
| Thread: | ＜3L with 17E |
| ≥3L with 25E | |
| Finish: | white powder coating (standard finish) |
| brushed polish / clear coating (optional) | |
| Graphic: | label / silkscreen logo (optional) |
| Accessories: | valve / carrying handle installed upon request |
| Model | Work Pressure (bar) | Test Pressure (bar) | Water Volume (l) | O₂ Capacity (l) | Diameter (mm) | Length (mm) | Weight (kg) | Thread |
| TPED-M0.3 | 200 | 300 | 0.3 | 59.22 | 60 | 200 | 0.47 | 17E |
| TPED-M0.5 | 200 | 300 | 0.5 | 98.69 | 70 | 240 | 0.74 | 17E |
| TPED-M1 | 200 | 300 | 1.0 | 197.38 | 101 | 230 | 1.57 | 17E |
| TPED-M2 | 200 | 300 | 2.0 | 394.77 | 101 | 400 | 2.55 | 17E |
| TPED-M3 | 200 | 300 | 3.0 | 592.15 | 111 | 490 | 3.73 | 25E |
| TPED-M4 | 200 | 300 | 4.0 | 789.54 | 111 | 630 | 4.70 | 25E |
| TPED-M5 | 200 | 300 | 5.0 | 986.92 | 140 | 535 | 6.54 | 25E |
| TPED-M10 | 200 | 300 | 10.0 | 1973.85 | 175 | 668 | 12.83 | 25E |
| TPED-M20 | 200 | 300 | 20.0 | 3947.69 | 203 | 940 | 23.29 | 25E |
| TPED-M30 | 200 | 300 | 30.0 | 5921.54 | 229 | 1110 | 34.57 | 25E |
| TPED-M40 | 200 | 300 | 40.0 | 7895.39 | 250 | 1230 | 45.54 | 25E |
| TPED-M50 | 200 | 300 | 50.0 | 9869.23 | 250 | 1500 | 54.64 | 25E |
| Custom dimensions / specifications available upon request | ||||||||
