| Material: | AA6061-T6 |
| Specification: | ISO 7866 compliant |
| TPED Pi (2010/35/EU) certified | |
| Volume: | 0.3L- 21.3L |
| Diameter: | 60, 70, 89, 111, 120, 140, 152, 159, 203 mm |
| Thread: | ≤2.67L with 17E / M18x1.5 |
| ＞2.67L with 25E / M25x2 | |
| Finish: | brushed polish (standard finish) |
| powder coating / clear coating (optional) | |
| Graphic: | shrink sleeve / label / silkscreen logo (optional) |
| Accessories: | valve / carrying handle installed upon request |
| Model | Work Pressure (bar) | Test Pressure (bar) | Water Volume (l) | CO₂ Capacity (kg) | Diameter (mm) | Length (mm) | Weight (kg) | Thread |
| TPED-B0.45 | 166.7 | 250 | 0.6 | 0.45 | 60 | 330 | 0.62 | M18x1.5 |
| TPED-B0.75 | 166.7 | 250 | 1.0 | 0.75 | 89 | 268 | 1.18 | M18x1.5 |
| TPED-B1 | 166.7 | 250 | 1.34 | 1.0 | 89 | 345 | 1.46 | 17E |
| TPED-B1.5 | 166.7 | 250 | 2.0 | 1.5 | 111 | 340 | 2.38 | 17E |
| TPED-B2 | 166.7 | 250 | 2.67 | 2.0 | 111 | 442 | 2.89 | 17E |
| TPED-B2A | 166.7 | 250 | 2.67 | 2.0 | 120 | 380 | 3.03 | 17E |
| TPED-B3 | 166.7 | 250 | 4.0 | 3.0 | 140 | 420 | 4.49 | 25E |
| TPED-B4 | 166.7 | 250 | 5.4 | 4.0 | 140 | 532 | 5.47 | 25E |
| TPED-B5 | 166.7 | 250 | 6.7 | 5.0 | 152 | 570 | 6.73 | 25E |
| TPED-B6 | 166.7 | 250 | 8.0 | 6.0 | 152 | 656 | 7.73 | 25E |
| TPED-B10 | 166.7 | 250 | 13.4 | 10.0 | 203 | 636 | 14.19 | 25E |
| TPED-B15 | 166.7 | 250 | 20.0 | 15.0 | 203 | 900 | 19.09 | 25E |
| Custom dimensions / specifications available upon request | ||||||||
